Components
Technical specs
-
Frame
Foxy 29 Stealth Air full Carbon, Zero Suspension System, 150mm travel, Forward Geometry, aluminium CSC upper link with carbon bridge, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors. *Geometry kit included
Sizes
S: 380mm / M: 420mm / L: 470mm / XL: 510mm
-
Rear shock
Öhlins TTX Air 205x62.5mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings
Shock settings
C20 compression, R35 rebound
-
Fork
Öhlins RXF 36 M.2 29, 170mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber
Headset
Onoff Titan tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41.8x30.5x8x45ºx45º, bottom 51.9x40x8x45ºx45º
-
Stem
Onoff Krypton FG 30mm, 6061 forged alloy, 31.8mm barbore
Handlebar
Onoff Kripton Carbon 0.5, rise: 12,5mm, width: 780mm, 9º backsweep, 5º upsweep, 31.8mm barbore
-
Grips
Onoff Desert, 1lock-on, 135mm, sizes: S/M L/XL
Seatpost
Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L size: 425x150mm, XL size: 465x170mm
-
Saddle
SDG BEL-AIR 3.0, EVA foam, steel rails
Front brake
Sram G2 RSC, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
-
Rear brake
Sram G2 RSC, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever
Sram G2 RSC, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
-
Rims
DT Swiss EXC1501 Carbon Spline 29, 30mm internal width, hookless, tubeless ready, 28 spokes
Spokes
DT Competition, straightpull
-
Front hub
DT 240, Boost 15x110mm, IS 6 bolts
Rear hub
DT 240, Boost 12x148mm, 36T Ratchet EXP system, IS 6 bolts, XD freehub
-
Front tire
Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Rear tire
Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
-
Crankset
Sram X01 Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
Rings
32T, CNC-machined alloy, X-SYNC 2
-
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
Chain
Sram GX Eagle, 12s, Powerlock
-
Rear derrailleur
Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers
Sram Trigger X01 Eagle, 12s, X-Actuation 1:1
-
Casette
Sram XG-1295, 10-52T, 12s
Derailleur hanger
Mondraker M068
-
Others
*Geometry kit included: steering cups: +/- 1º
Weight
13.3 kg
